Additional information
| Weight | 5 kg |
|---|
€525.00
-
Approx. 13% Faster Drilling Speed*1
Approx. 28% More Demolition Performance*2- A comparison between the DH40MC and previous model DH40MR. (When drilling ø16-40mm holes into concrete. Actual results vary depending on
conditions.) - A comparison between the DH40MC and previous model DH40MR. (Actual
results vary depending on conditions.)
- A comparison between the DH40MC and previous model DH40MR. (When drilling ø16-40mm holes into concrete. Actual results vary depending on
Superior Working Comfort
-
A larger damper and higher volume air cushion reduce the impact and piston reaction force generated during hammering. This results in
significant vibration reduction.
- A comparison between the DH40MC and previous model DH40MR. (Actual results vary depending on conditions.)
One Push Bit Mounting
-
It only takes one action instead of conventionally-required two to mount a drill bit. All that needs to be done is insert the drill bit into the tool holder while
turning it.
Large Change Lever
-
Large change lever located on top of the tool for easy visibility allows smooth mode changing.
– Hammering (for demolition)
– Neutral (for bit angle adjustment)
– Rotation + Hammering (for drilling)
Multiple Bit-Angle Settings
-
The chisel can be rotated at 12 different angles with the change lever
positioned at ‘neutral’.
Large Trigger Switch
-
Large trigger switch is easy to grip and fit the hand for more control with less
fatigue.
Specifications
| Capacity | Drill Bit | 40mm (1-9/16″) |
|---|---|---|
| Core Bit | 105mm (4-1/8″) | |
| Power Input | 1,100W | |
| Bit Shank | SDS max | |
| No Load Speed | 620/min. | |
| Full Load Impact Rate | 2,800/min. | |
| Overall Length | 448mm (17-5/8″) | |
| Weight (including side handle) | 7.1kg (15.6lbs.) | |
| Vibration Total Values (triax vector sum)* |
Hammer drilling into concrete |
Vibration emission value : ah, HD = 16.5m/s2 Uncertainty K = 1.5 m/s2 |
| Equivalent chiselling value | Vibration emission value : ah, CHeq = 13.3m/s2 Uncertainty K = 1.5m/s2 |
|
| Standard Accessories | Side Handle, Stopper, Hammer Grease A (30g), Carrying Case | |
- Vibration total values (triax vector sum) determined according to EN60745.
