Additional information
| Weight | 5 kg |
|---|
€969.00
Features
- XACT CUT LED: Precise shadow cutting line without re-adjustment thanks to cleverly positioned LED
- Convenient bevel adjustment on the front
- Compact sliding system with double guides increases stability and prevents extension to the rear when working close to the wall
- The table can be extended on the right and the left for sawing wide workpieces
- Positive stops for fast and accurate mitre adjustments
Specifications
| Input power | 1,520 W |
|---|---|
| Motor type | Universal |
| Saw blade diameter | 305 mm |
| Bore hole diameter | 30 mm |
| No-load speed capacity | 4,000 rpm |
| Bevel capacity | Left / right 0° – 45° |
| Mitre angle | Left 0° – 45° / right 0° – 57° |
| Cutting capacity (H x L) | 0° – 105 x 312 mm |
| 45° left – 68 x 312 mm | |
| 45° right – 43 x 312 mm | |
| 0° + mitre left 45° – 105 x 220 mm | |
| 0° + mitre right 45° – 105 x 220 mm | |
| 45° left + mitre l/r 45° – 68 x 220 mm | |
| 45° right + mitre l/r 45° – 43 x 220 mm | |
| Double bevel | YES |
| Bevel lock on front | YES |
| Compact sliding system | YES |
| Shadow line | YES |
| Dimensions (l x W x H) | 655 x 873 x 724 mm) |
| Tool weight | 25.5 kg |
